LED

Features LED

Specifications:1.
Color ints：The color int always defines a color in the color space using 4 components packed in a single 32-bit integer value:Component Size RangeBrightness 8 bits [0…255]Red 8 bits [0…255]Green 8 bits [0…255]Blue 8 bits [0…255]2.
Command:Send change LED broadcast shell command (root):am broadcast -a action.CHANGE_LED_COLOR --ei color xx is a decimal number.
3.
Hexadecimal and decimal conversion tables.Brightness: 0B; Color: 01 light, 70 deep (hexadecimal)Color Hexadecimal DecimalDark red 0B700000 191889408Dark green 0B007000 184578048Dark blue 0B000070 184549488Light red 0B010000 184614912Light green 0B000100 184549632Light blue 0B000001 184549377Yellow 0B707000 191918080Purple 0B700070 191889520White 0B707070 191918192Close the lamp 0 0
